Deploying kudurru

Shape	Guide	Assets
One container (Docker, Podman)	docker.md	`deploy/compose/single`, `deploy/compose/single-edge`
Three hosts with a VIP (dnsdist + keepalived, `ha-static`)	compose-ha.md	`deploy/compose/ha/node-{a,b,c}`
Kubernetes with Helm	helm.md	`charts/kudurru`, `charts/kudurru-crds`
Kubernetes with kustomize	kustomize.md	`config/`
Linux packages (deb, rpm, apk) with systemd	docker.md#linux-packages-and-systemd	`deploy/systemd`
Monitoring	helm.md#monitoring	`deploy/grafana/kudurru-overview.json`, `deploy/prometheus/rules.yaml`

Runbooks: cold start without the apiserver, key rotation, upgrades. Blocked services and safe search, and the runtime catalogue URL: blocked-services.md. Allowlist, Denylist and switching single entries of any list off: allowlist.md. The block page (blocked names open a page explaining the block, with a Request access form administrators answer on the Requests page): blocking-page.md.

Release artifacts

Releases are cut by merging main into release-candidate (a v<version>-rc.<N> pre-release) and release-candidate into release (the v<version> release, which also moves latest); the version comes from the VERSION file (release-checklist.md). Both run .github/workflows/publish.yml, which runs goreleaser (.goreleaser.yaml) and publishes:

ghcr.io/robertherbaugh/kudurru:<version>: distroless static, nonroot (uid 65532), linux/amd64 and linux/arm64, built by ko, with an SPDX SBOM and a cosign keyless signature; <version>-debug adds busybox (a shell and nslookup); a release also moves latest (and latest-debug), a release candidate does not;
binaries for linux and darwin on amd64 and arm64, deb/rpm/apk packages with a hardened systemd unit, a compose bundle, crds.yaml and install.yaml (kustomize build config/default), all covered by checksums.txt, which is cosign-signed, plus GitHub build provenance;
the Helm charts at oci://ghcr.io/robertherbaugh/charts/kudurru and .../kudurru-crds, cosign-signed.

Every pull request against main also pushes ghcr.io/robertherbaugh/kudurru:dev-<PR number> (unsigned, for testing the branch; later pushes overwrite it).

Verify an image:

cosign verify ghcr.io/robertherbaugh/kudurru:0.1.0 \
  --certificate-identity-regexp '^https://github\.com/robertherbaugh/kudurru/\.github/workflows/publish\.yml@refs/heads/release(-candidate)?$' \
  --certificate-oidc-issuer https://token.actions.githubusercontent.com

Ports

Port	Protocol	Purpose
53	udp, tcp	DNS (5353 PROXYv2-only behind the dnsdist edge)
853	tcp / udp	DNS over TLS / DNS over QUIC
443	tcp / udp	DNS over HTTPS / HTTP/3
8080	tcp	API and UI
8081	tcp	ops: `/healthz/startup`, `/healthz/ready`, `/healthz/live` (no auth)
8082	tcp	internal node-to-node listener (always TLS)
8084	tcp	edge supervisor readiness
80, 443	tcp	block page (optional, `listeners.blockPage`; 8090/8493 in the chart and compose containers)
8888	tcp	external-dns webhook provider (optional)
9153	tcp	Prometheus `/metrics`

Secrets

The binary reads secrets from files named by environment variables, never from the config file:

Variable	Content
`KUDURRU_ENCRYPTION_KEY_FILE`	32 random bytes, base64 or 64 hex digits (`openssl rand -base64 32`). Seals sessions and stored secrets and derives the internal listener's token and CA (D47, D92). Required in Kubernetes; every node of a cluster shares it.
`KUDURRU_ENCRYPTION_KEY_PREVIOUS_FILE`	The previous key during a rotation (runbooks.md).
`KUDURRU_ADMIN_PASSWORD_FILE`	Password of the first-start `admin` user; read only while no user exists.
`KUDURRU_BOOTSTRAP_TOKEN_FILE`	Optional `kdr_<id>_<secret>` token created at first start for automation.

Every settings key can also be set as KUDURRU_<SECTION>__<KEY> (for example KUDURRU_LOG__LEVEL=debug) or KUDURRU_<SECTION>__<KEY>_FILE; list and map keys (listeners, upstream groups) only from the file. An environment variable that names no key stops the server at start, so typos do not go unnoticed. kudurru config schema lists every key.
